| Nama Wahi | AM-1024768R2TNQW-T00H |
| Waitohu | AMPIRE |
| Rahi | 12.1 |
| Taupānga | Industrial |
| Whakatau | 1024×768 |
| Te tito | a-Si TFT-LCD , LCM |
| Tirohanga | |
| CR | 800:1 |
| Nga Tae | 262K/16.7M |
| Whakamuri | 10S5P |
| Atanga | LVDS |
| panel brand | AMPIRE |
| panel size | 12.1" |
| resolution | 1024(RGB)×768, XGA, 105PPI |
| display area | 245.76(W)×184.32(H) mm |
| outline size | 279(W)×209(H) ×11.2(D) mm |
| brightness | 850 cd/m² (Typ.) |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10) |
| best view on | - |
| display colors | 262K/16.7M |
| frequency | 60Hz |
| panel weight | - |
| signal interface | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| input voltage | 3.3V (Typ.) |
| environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| panel model | AM-1024768R2TNQW-T00H |
| panel type | a-Si TFT-LCD , LCM |
| pixel format | RGB Vertical Stripe |
| bezel opening | - |
| surface | - |
| contrast ratio | 800:1 (Typ.) (TM) |
| display mode | TN, Normally White, Transmissive |
| response time | 16 (Typ.)(Tr+Td) |
| lamp type | 10S5P WLED , 50K hours , Without Driver |
| touch screen | PCAP |
| application | Industrial |
