| Nama Wahi | AG-320240A4FIQW-K9H-S(N)(R) |
| Waitohu | AMPIRE |
| Rahi | 5.7 |
| Taupānga | IA |
| Whakatau | 320×240 |
| Te tito | LCM |
| Tirohanga | |
| CR | |
| Nga Tae | Monochrome |
| Whakamuri | WLED |
| Atanga | CPU |
| panel brand | AMPIRE |
| panel model | AG-320240A4FIQW-K9H-S(N)(R) |
| panel type | FSTN-LCD , LCM |
| panel size | 5.7 inch |
| resolution | 320×240 , QVGA |
| display mode | STN, Transflective |
| active area | 115.185×86.385 mm |
| outline | 167×104.7×14.5 mm |
| surface | |
| brightness | |
| contrast ratio | |
| display colors | Monochrome |
| response time | 200/200 (Typ.)(Tr/Td) |
| viewing angle | 30/30/35/30 (Typ.)(CR≥10)(L/R/U/D) |
| lamp type | 1S6PWLEDWithout Driver |
| signal interface | 8-bit 6080/8080 parallel, 24 pins |
| input voltage | 5.0V (Typ.) |
| application | IA |
