| Nama Wahi | A030VAC01.1 |
| Waitohu | AUO |
| Rahi | 3.0 |
| Taupānga | Digital Still Camera |
| Whakatau | 720×480 |
| Te tito | LCM , a-Si TFT-LCD |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | 6S1P |
| Atanga | Serial |
| manufacturer | AUO |
| model name | A030VAC01.1 |
| screen size | 3.0 inch |
| screen type | LCM , a-Si TFT-LCD |
| pixel number | 720(RGB)×480 287PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 63.72 × 42.48 (H×V) |
| outline(mm) | 78 × 51.1 (H×V×D) |
| bezel area(mm) | - |
| treatment | Hard coating (6H) |
| luminance | 350 cd/m² (Typ.) |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10) |
| response | 18/18 (Typ.)(Tr/Td) ms |
| good view at | - |
| work mode | TN, Normally White, Transmissive |
| color depth | 16.7M 70% NTSC |
| backlight | 6S1P WLED , No Driver |
| mass | 27.0g (Typ.) |
| used for | Digital Still Camera Digital Video Camera |
| refresh rate | - |
| touchscreen | Without |
| signal type | Serial RGB (8-bit) + SPI , 51 pins FPC |
| voltage supply | 1.8/3.0V (Typ.)(VDDIO/VDD) |
| max. ratings | Storage Temp.: -25 ~ 70 °C Operating Temp.: -10 ~ 60 °C |
