| Nama Wahi | A030JTN01.1 |
| Waitohu | AUO |
| Rahi | 3.0 |
| Taupānga | DSC |
| Whakatau | 960×480(dot) |
| Te tito | LCM |
| Tirohanga | 550 |
| CR | 300:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | YUV |
| panel brand | AUO |
| panel model | A030JTN01.1 |
| panel type | LTPS TFT-LCD , LCM |
| panel size | 3.0 inch |
| resolution | 960×480 |
| display mode | TN, Normally White, Transmissive |
| active area | 60×45 mm |
| outline | 69.65×50.9 mm |
| surface | Hard coating |
| brightness | 550 cd/m² (Typ.) |
| contrast ratio | 300:1 (Typ.) |
| display colors | 16.7M (8-bit), CIE193144% |
| response time | 10/25 (Typ.)(Tr/Td) |
| viewing angle | 45/45/20/45 (Typ.)(CR≥10)0(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 4S1PWLEDWithout Driver |
| signal interface | YUV (16-bit), 47 pins |
| input voltage | 3.3/3.3V (Typ.)(VDD/VDDIO) |
| application | DSC |
