AUO A027DN01 VB Raraunga Raarangi, Whakatakotoranga, rakau, tono www.looklcd-no.com
LookLCD LookLCD


A027DN01 VB

A027DN01 VB
A027DN01 VB thumb
Waitohu
AUO
Rahi
2.7
Taupānga
DSC
Whakatau
320×240
Te tito
LCM
Tirohanga
250
CR
300:1
Nga Tae
16.7M
Whakamuri
WLED
Atanga
Serial RGB
In Stock
7919
Whakatakotoranga

Nama Wahi A027DN01 VB
WaitohuAUO
Rahi2.7
TaupāngaDSC
Whakatau320×240
Te titoLCM
Tirohanga250
CR300:1
Nga Tae16.7M
WhakamuriWLED
AtangaSerial RGB
panel brandAUO
panel modelA027DN01 VB
panel type a-Si TFT-LCD , LCM
panel size2.7 inch
resolution320(RGB)×240 , QVGA
display modeTN, Normally White, Transmissive
active area54×40.5 mm
outline63.5×46.6 mm
surfaceGlare (Haze 0%)
brightness250 cd/m² (Typ.)
contrast ratio300:1 (Typ.)
display colors16.7M (8-bit)
response time10/25 (Typ.)(Tr/Td)
viewing angle60/60/50/60 (Typ.)(CR≥10)(L/R/U/D)
lamp type1 pcsWLED
signal interfaceSerial RGB (8-bit) + SPI, CCIR601/656, 39 pins
input voltage3.3V (Typ.)(VDD)
applicationDSC
Tauira Whanau
A027DN01 VQ AUO 2.7 320×240
A027DN01 VR AUO 2.7 320×240
A027DN03 V1 AUO 2.7 320×240
A027DN03 V3 AUO 2.7 320×240
A027DN03 V7 AUO 2.7 320×240
A027DN03 V8 AUO 2.7 320×240
A027DN03 V9 AUO 2.7 320×240
A027DN04 V4 AUO 2.7 320×240
A027DN04 V8 AUO 2.7 320×240
A027DTN01.3 AUO 2.7 320×240
