Nama Wahi | 700408 |
Waitohu | Plastic Logic |
Rahi | 4.7 |
Taupānga | Handheld & PDA |
Whakatau | 800×450 |
Te tito | EPD, EPD |
Tirohanga | |
CR | |
Nga Tae | Grayscale |
Whakamuri | No |
Atanga | Parallel |
manufacturer | Plastic Logic |
model name | 700408 |
screen size | 4.7 inch |
screen type | EPD, EPD |
pixel number | 800×450 195PPI |
arrangement | Rectangle |
active area(mm) | 103.68 × 58.32 (H×V) |
outline(mm) | 117.26 × 62.1 × 0.75 (H×V×D) |
bezel area(mm) | - |
treatment | Antiglare, Hard coating (2H) |
viewing angle | - |
response | 900 (Max.)(4 gray-level) ms |
good view at | - |
work mode | Reflective |
color depth | Grayscale |
backlight | No B/L |
mass | 6.00g (Typ.) |
used for | Handheld & PDA |
refresh rate | - |
touchscreen | Without |
signal type | Parallel Data (1ch, 8-bit) , FPC 44 pins |
max. ratings | Storage Temp.: -25 ~ 50 °C Operating Temp.: 0 ~ 50 °C |
