| Nama Wahi | WG12232C-TMI-T#A |
| Waitohu | Winstar |
| Rahi | 2.2 |
| Taupānga | Industrial Instrumen |
| Whakatau | 122×32 |
| Te tito | LCM , STN-LCD |
| Tirohanga | |
| CR | 3:1 |
| Nga Tae | Monochrome |
| Whakamuri | WLED |
| Atanga | 8-bit |
| manufacturer | Winstar |
| model name | WG12232C-TMI-T#A |
| screen size | 2.2 inch |
| screen type | LCM , STN-LCD |
| pixel number | 122×32 57PPI |
| arrangement | Rectangle |
| active area(mm) | 53.64 × 15.64 (H×V) |
| outline(mm) | 84 × 44 × 14.2 (H×V×D) |
| bezel area(mm) | 60.0 × 18.0 (H×V) |
| treatment | - |
| luminance | - |
| contrast ratio | 3 : 1 (Typ.) (TM) |
| viewing angle | 30/30/20/40 (Typ.)(CR≥2) |
| response | 100/100 (Typ.)(Tr/Td) ms |
| good view at | 6 o'clock |
| work mode | STN, Blue mode (Negative), Transmissive |
| color depth | Monochrome |
| backlight | WLED , 50K hours , No Driver |
| mass | - |
| used for | Industrial Instruments & Meters |
| refresh rate | - |
| touchscreen | Without |
| signal type | 8-bit 6800/8080 parallel , 20 pins Pad |
| voltage supply | 5.0V (Typ.) |
| max. ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
