| Nama Wahi | WF57STIACDNG0 |
| Waitohu | Winstar |
| Rahi | 5.7 |
| Taupānga | Industrial |
| Whakatau | 320×240 |
| Te tito | a-Si TFT-LCD , LCM |
| Tirohanga | |
| CR | 800:1 |
| Nga Tae | Grayscale |
| Whakamuri | WLED |
| Atanga | 8/16-bit |
| brand | Winstar |
| diagonal size | 5.7 inch |
| pixel format | 320×240 [QVGA] 70PPI |
| active area | 115.2(H)×86.4(V) mm |
| bezel area | 117.9(H)×89.1(V) mm |
| luminance | 800 cd/m² (Typ.) |
| view direction | 12 o'clock |
| viewing angle | - |
| support color | Grayscale |
| weight | - |
| frame rate | - |
| interface type | 8/16-bit 6800/8080 parallel, 3/4-wire SPI , 22 pins FPC |
| power supply | 3.3V (Typ.) |
| environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| model | WF57STIACDNG0 |
| type | a-Si TFT-LCD , LCM |
| configuration | Rectangle |
| outline dim. | 160(H)×109(V) ×9.24(D) mm |
| treatment | Glare (Haze 0%) |
| contrast ratio | 800:1 (Typ.) (TM) |
| response time | - |
| operating mode | TN, Normally White, Transmissive |
| light source | WLED , W/O Driver |
| designed for | Industrial |
| touch panel | PCAP |
| AM-640480G4TNQW-T01H | AMPIRE | 5.7 | 640×480 |
| AM-640480GFTNQW-T01H-L | AMPIRE | 5.7 | 640×480 |
| COM57H5M10XRC | ORTUSTECH | 5.7 | 640×480 |
| DLC0570BDG-T-2 | Other | 5.7 | 640×480 |
| KG057QV1CA-G01 | Kyocera | 5.7 | 320×240 |
| LM32004 | SHARP | 5.7 | 320×240 |
| NL6448BC18-01 | NLT | 5.7 | 640×480 |
| NL6448BC18-03F | NLT | 5.7 | 640×480 |
| SP14Q001 | KOE | 5.7 | 320×240 |
| TM057QDHG04 | Tianma | 5.7 | 640×480 |
