| Nama Wahi | VTF231BJ02 |
| Waitohu | BOE |
| Rahi | 23.1 |
| Taupānga | Digital Signage Stre |
| Whakatau | 1920×158 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | BOE |
| panel model | VTF231BJ02 |
| panel size | 23.1" |
| panel type | a-Si TFT-LCD, LCM |
| resolution | 1920×158(RGB), 83PPI |
| pixel format | RGB Horizontal Stripe |
| display area | 585.216(W)×48.158(H) mm |
| bezel opening | 587.5(W)×49.8(H) mm |
| outline size | 597.2(W)×60.2(H) ×17.1(D) mm |
| surface | Antiglare (Haze 25%), Hard coating (3H) |
| brightness | 400 cd/m² (Typ.) |
| contrast ratio | 1000:1 (Typ.) (TM) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| display mode | ADS, Normally Black, Transmissive |
| best view on | Symmetry |
| response time | 15 (Typ.)(G to G) |
| display colors | 16.7M 72% NTSC |
| lamp type | WLED , 30K hours , With LED Driver |
| frequency | 60Hz |
| touch screen | Without |
| panel weight | 450g (Typ.) |
| application | Digital Signage Stretched Bar LCD |
| signal interface | LVDS (1 ch, 8-bit) , 30 pins Connector |
| input voltage | 12.0V (Typ.) |
| environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| LQ231U1LW01 | SHARP | 23.1 | 1600×1200 |
| LQ231U1LW21 | SHARP | 23.1 | 1600×1200 |
