| Nama Wahi | TV101WXM-NS0 |
| Waitohu | BOE |
| Rahi | 10.1 |
| Taupānga | Pad & Tablet |
| Whakatau | 1280×800 |
| Te tito | a-Si TFT-LCD , LCM |
| Tirohanga | |
| CR | 900:1 |
| Nga Tae | 16.7M |
| Whakamuri | 6 |
| Atanga | LVDS |
| panel brand | BOE |
| panel size | 10.1" |
| resolution | 1280(RGB)×800, WXGA, 149PPI |
| display area | 216.96(W)×135.6(H) mm |
| outline size | 228.211(W)×148.86(H) ×4.59(D) mm |
| brightness | - |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10) |
| best view on | Symmetry |
| display colors | 16.7M 50% NTSC |
| frequency | 60Hz |
| panel weight | 130g (Typ.) |
| signal interface | LVDS (1 ch, 8-bit) , 45 pins Connector |
| input voltage | 3.3V (Typ.) |
| environment | Operating Temp.: -20 ~ 65 °C ; Storage Temp.: -40 ~ 80 °C |
| panel model | TV101WXM-NS0 |
| panel type | a-Si TFT-LCD , LCM |
| pixel format | RGB Vertical Stripe |
| bezel opening | - |
| surface | Hard coating (2H), Antireflection |
| contrast ratio | 900:1 (Typ.) (TM) |
| display mode | ADS, Normally Black, Transmissive |
| response time | 30 (Typ.)(Tr+Td) |
| lamp type | 6 strings WLED , Without Driver |
| touch screen | Without |
| application | Pad & Tablet |
