| Nama Wahi | TMS150XG1-10TB |
| Waitohu | Tianma |
| Rahi | 15.0 |
| Taupānga | DMPC |
| Whakatau | 1024×768 |
| Te tito | LCM |
| Tirohanga | 250 |
| CR | 600:1 |
| Nga Tae | 16.7M |
| Whakamuri | CCFL |
| Atanga | LVDS |
| panel brand | AVIC |
| panel model | TMS150XG1-10TB |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 15.0 inch |
| resolution | 1024(RGB)×768 , XGA |
| display mode | TN, Normally White, Transmissive |
| active area | 304.128×228.096 mm |
| outline | 326.5×253.5×12 mm |
| surface | Antiglare |
| brightness | 250 cd/m² (Typ.) |
| contrast ratio | 600:1 (Typ.) |
| display colors | 16.7M (6-bit + Hi-FRC), CIE193160% |
| response time | 2/6 (Typ.)(Tr/Td) |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 2 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 8-bit), 20 pins |
| input voltage | 3.3V (Typ.) |
| application | DMPC |
