| Nama Wahi | TM104TDGP10 |
| Waitohu | TIANMA |
| Rahi | 10.4 |
| Taupānga | Industrial |
| Whakatau | 1024×768 |
| Te tito | a-Si TFT-LCD , LCM |
| Tirohanga | |
| CR | 1200:1 |
| Nga Tae | 262K/16.7M |
| Whakamuri | 8S4P |
| Atanga | LVDS |
| panel brand | TIANMA |
| panel size | 10.4" |
| resolution | 1024(RGB)×768, XGA, 123PPI |
| display area | 210.432(W)×157.824(H) mm |
| outline size | 230(W)×175.8(H) ×9.06(D) mm |
| brightness | 450 cd/m² (Typ.) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| best view on | Symmetry |
| display colors | 262K/16.7M 50% NTSC |
| frequency | 60Hz |
| panel weight | 430g (Typ.) |
| signal interface | LVDS (1 ch, 6/8-bit) , 20 pins Connector |
| input voltage | 3.3V (Typ.) |
| environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| panel model | TM104TDGP10 |
| panel type | a-Si TFT-LCD , LCM |
| pixel format | RGB Vertical Stripe |
| bezel opening | 213.43(W)×160.82(H) mm |
| surface | Antiglare |
| contrast ratio | 1200:1 (Typ.) (TM) |
| display mode | SFT, Normally Black, Transmissive |
| response time | 35 (Typ.)(Tr+Td) |
| lamp type | 8S4P WLED , With LED Driver |
| touch screen | Without |
| application | Industrial |
| LB104S01-TL02 | LG Display | 10.4 | 800×600 |
| LQ104V1DW02 | SHARP | 10.4 | 640×480 |
| LQ10D131 | SHARP | 10.4 | 640×480 |
| LTM10C348F | TOSHIBA | 10.4 | 800×600 |
| TM104QDSG09 | Tianma | 10.4 | 640×480 |
| TM104SBH01 | Tianma | 10.4 | 800×600 |
| TM104SCH02 | Tianma | 10.4 | 800×600 |
| TM104SDH01 | Tianma | 10.4 | 800×600 |
| TM104SDH02 | Tianma | 10.4 | 800×600 |
| TM104SDHG30 | Tianma | 10.4 | 800×600 |
