| Nama Wahi | TM101DDHG05 |
| Waitohu | TIANMA |
| Rahi | 10.1 |
| Taupānga | Industrial |
| Whakatau | 1024×600 |
| Te tito | a-Si TFT-LCD , LCM |
| Tirohanga | |
| CR | 500:1 |
| Nga Tae | 262K/16.7M |
| Whakamuri | WLED |
| Atanga | |
| brand | TIANMA |
| diagonal size | 10.1 inch |
| pixel format | 1024(RGB)×600 [WSVGA] 117PPI |
| active area | 222.72(H)×125.28(V) mm |
| bezel area | - |
| luminance | 1400 cd/m² (Typ.) |
| view direction | 12 o'clock |
| viewing angle | 80/80/75/80 (Typ.)(CR≥10) |
| support color | 262K/16.7M 47% NTSC |
| weight | - |
| frame rate | 60Hz |
| model | TM101DDHG05 |
| type | a-Si TFT-LCD , LCM |
| configuration | RGB Vertical Stripe |
| outline dim. | 235(H)×143(V) ×7.8(D) mm |
| treatment | Antiglare, Hard coating |
| contrast ratio | 500:1 (Typ.) (TM) |
| response time | 7/9 (Typ.)(Tr/Td) |
| operating mode | TN, Normally White, Transmissive |
| light source | WLED [14S3P] , 30K hours , W/O Driver |
| designed for | Industrial |
| touch panel | Without |
