| Nama Wahi | TM101DDHG04 |
| Waitohu | TIANMA |
| Rahi | 10.1 |
| Taupānga | Industrial |
| Whakatau | 1024×600 |
| Te tito | a-Si TFT-LCD , LCM |
| Tirohanga | |
| CR | 800:1 |
| Nga Tae | 262K/16.7M |
| Whakamuri | 10S3P |
| Atanga | |
| panel brand | TIANMA |
| panel size | 10.1" |
| resolution | 1024(RGB)×600, WSVGA, 117PPI |
| display area | 222.72(W)×125.28(H) mm |
| outline size | 233.1(W)×137.1(H) ×3.3(D) mm |
| brightness | 300 cd/m² (Typ.) |
| viewing angle | 80/80/75/80 (Typ.)(CR≥10) |
| best view on | 12 o'clock |
| display colors | 262K/16.7M 47% NTSC |
| frequency | 60Hz |
| weight | 210/220g (Typ./Max.) |
| panel model | TM101DDHG04 |
| panel type | a-Si TFT-LCD , LCM |
| pixel format | RGB Vertical Stripe |
| bezel opening | 225.72(W)×128.28(H) mm |
| surface | Antiglare, Hard coating (3H) |
| contrast ratio | 800:1 (Typ.) (TM) |
| display mode | TN, Normally White, Transmissive |
| response time | 7/9 (Typ.)(Tr/Td) |
| lamp type | 10S3P WLED , 15K hours , Without Driver |
| touch screen | Without |
| application | Industrial |
