| Nama Wahi | TM097QDSP01 |
| Waitohu | TIANMA |
| Rahi | 9.7 |
| Taupānga | Pad & Tablet |
| Whakatau | 1536×2048 |
| Te tito | LCM , a-Si TFT-LCD |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | 6S6P |
| Atanga | MIPI |
| manufacturer | TIANMA |
| model name | TM097QDSP01 |
| screen size | 9.7 inch |
| screen type | LCM , a-Si TFT-LCD |
| pixel number | 1536(RGB)×2048 (QXGA) 264PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 147.456 × 196.608 (H×V) |
| outline(mm) | 154.016 × 207.83 × 3.75 (H×V×D) |
| bezel area(mm) | - |
| treatment | Hard coating |
| luminance | 460 cd/m² (Typ.) |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| response | 25 (Typ.)(Tr+Td) ms |
| good view at | Symmetry |
| work mode | SFT, Normally Black, Transmissive |
| color depth | 16.7M 72% NTSC |
| backlight | 6S6P WLED , No Driver |
| mass | 110g (Typ.) |
| used for | Pad & Tablet |
| refresh rate | 60Hz |
| touchscreen | Without |
| signal type | MIPI (2 ch, 4 data lanes) , 61 pins Connector |
| voltage supply | 1.8/5.0/-5.0V (Typ.)(VDDI/AVDD/AVEE) |
| max. ratings | Storage Temp.: -30 ~ 70 °C Operating Temp.: -10 ~ 60 °C |
| BF097XN | Innolux | 9.7 | 1024×768 |
| LP097QX1-SPA1 | LG Display | 9.7 | 2048×1536 |
| LP097QX1-SPAV | LG Display | 9.7 | 2048×1536 |
| LP097QX2-SPAV | LG Display | 9.7 | 1536×2048 |
| LP097QX3-SPAV | LG Display | 9.7 | 1536×2048 |
| LP097X02-SLQ1 | LG Display | 9.7 | 1024×768 |
| LQ097L1JY01A | SHARP | 9.7 | 2048×1536 |
| LTN097XL01-A01 | Samsung | 9.7 | 1024×768 |
| TM097TDH01 | Tianma | 9.7 | 1024×768 |
| TM097TDH02 | Tianma | 9.7 | 1024×768 |
