| Nama Wahi | TM084SDHG04 |
| Waitohu | TIANMA |
| Rahi | 8.4 |
| Taupānga | Industrial |
| Whakatau | 800×600 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 500:1 |
| Nga Tae | 262K |
| Whakamuri | 8S3P |
| Atanga | LVDS |
| panel brand | TIANMA |
| panel model | TM084SDHG04 |
| panel size | 8.4" |
| panel type | a-Si TFT-LCD, LCM |
| resolution | 800(RGB)×600, SVGA, 119PPI |
| pixel format | RGB Vertical Stripe |
| display area | 170.4(W)×127.8(H) mm |
| bezel opening | 173.0(W)×130.6(H) mm |
| outline size | 203(W)×143.5(H) ×7.05(D) mm |
| surface | Antiglare |
| brightness | 350 cd/m² (Typ.) |
| contrast ratio | 500:1 (Typ.) (TM) |
| viewing angle | 70/70/60/70 (Typ.)(CR≥10) |
| display mode | TN, Normally White, Transmissive |
| best view on | 12 o'clock |
| response time | 20 (Typ.)(Tr+Td) |
| display colors | 262K 40% NTSC |
| lamp type | 8S3P WLED , 30K hours , With LED Driver |
| frequency | 60Hz |
| touch screen | Without |
| panel weight | 240g (Typ.) |
| application | Industrial |
| signal interface | LVDS (1 ch, 6-bit) , 20 pins Connector |
| input voltage | 3.3V (Typ.) |
| environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| AA084XB01 | Mitsubishi | 8.4 | 1024×768 |
| B084SN01 V2 | AUO | 8.4 | 800×600 |
| LQ9D001 | SHARP | 8.4 | 640×480 |
| LQ9D024 | SHARP | 8.4 | 640×480 |
| NL6448BC26-27 | NLT | 8.4 | 640×480 |
| TM084SBHG04 | Tianma | 8.4 | 800×600 |
| TM084SDHG01 | Tianma | 8.4 | 800×600 |
| TM084SDHG02 | Tianma | 8.4 | 800×600 |
| TM084SDHG03 | Tianma | 8.4 | 800×600 |
| TM084SDHG50 | Tianma | 8.4 | 800×600 |
