| Nama Wahi | TM080TDHG01-42 |
| Waitohu | TIANMA |
| Rahi | 8.0 |
| Taupānga | Industrial |
| Whakatau | 1024×768 |
| Te tito | LCM , a-Si TFT-LCD |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 262K/16.7M |
| Whakamuri | 3S9P |
| Atanga | |
| manufacturer | TIANMA |
| screen size | 8.0 inch |
| pixel number | 1024(RGB)×768 (XGA) 160PPI |
| active area(mm) | 162.048 × 121.536 (H×V) |
| bezel area(mm) | 164.65 × 124.14 (H×V) |
| luminance | 400 (Typ.)(cd/m²) |
| viewing angle | 80/80/80/80 (Typ.)(CR≥10) |
| good view at | 12 o'clock |
| color depth | 262K/16.7M 50% NTSC |
| mass | 189g |
| refresh rate | 60Hz |
| model name | TM080TDHG01-42 |
| screen type | LCM , a-Si TFT-LCD |
| arrangement | RGB Vertical Stripe |
| outline(mm) | 183 × 141 × 3.7 (H×V×D) |
| treatment | Clear |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| work mode | TN, Normally White, Transmissive |
| response | 20 (Typ.)(Tr+Td) ms |
| backlight | 3S9P WLED , 30K hours , No Driver |
| used for | Industrial |
| touchscreen | Without |
| CLAA080LG02AW | CPT | 8.0 | 800×480 |
| HSD080IDW1-A00 | HannStar | 8.0 | 800×480 |
| L5F30614T23 | SANYO | 8.0 | 800×480 |
| L5F30614T64 | SANYO | 8.0 | 800×480 |
| LM64C219 | SHARP | 8.0 | 640×480 |
| LQ080Y5DG03 | SHARP | 8.0 | 800×480 |
| N080ICE-GB0 Rev.A0 | Innolux | 8.0 | 800×1280 |
| N080XCG-L21 | Innolux | 8.0 | 1024×768 |
| P080KDZ-3Z1 | Innolux | 8.0 | 1200×1920 |
| TM080TDHG01 | Tianma | 8.0 | 1024×768 |
