| Nama Wahi | TM070RDSG12 |
| Waitohu | TIANMA |
| Rahi | 7.0 |
| Taupānga | Industrial |
| Whakatau | 800×480 |
| Te tito | LCM, a-Si TFT-LCD |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 262K/16.7M |
| Whakamuri | 7S3P |
| Atanga | |
| manufacturer | TIANMA |
| model name | TM070RDSG12 |
| screen size | 7.0 inch |
| screen type | LCM, a-Si TFT-LCD |
| pixel number | 800(RGB)×480 (WVGA) 133PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 152.4 × 91.44 (H×V) |
| outline(mm) | 167 × 106.3 × 9.8 (H×V×D) |
| bezel area(mm) | 154.4 × 93.44 (H×V) |
| treatment | Antiglare |
| luminance | 400 cd/m² (Typ.) |
| contrast ratio | 1000 : 1 (Typ.) (TM) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| response | 20 (Typ.)(Tr+Td) ms |
| good view at | Symmetry |
| work mode | SFT, Normally Black, Transmissive |
| color depth | 262K/16.7M 70% NTSC |
| backlight | 7S3P WLED , 50K hours , With LED Driver |
| mass | 175g (Typ.) |
| used for | Industrial |
| refresh rate | 60Hz |
| touchscreen | Without |
| Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
