| Nama Wahi | TM070RDHG34 |
| Waitohu | TIANMA |
| Rahi | 7.0 |
| Taupānga | Industrial Outdoor H |
| Whakatau | 800×480 |
| Te tito | LCM, a-Si TFT-LCD |
| Tirohanga | |
| CR | 800:1 |
| Nga Tae | 16.7M |
| Whakamuri | 3S8P |
| Atanga | |
| manufacturer | TIANMA |
| model name | TM070RDHG34 |
| screen size | 7.0 inch |
| screen type | LCM, a-Si TFT-LCD |
| pixel number | 800(RGB)×480 (WVGA) 134PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 154.08 × 85.92 (H×V) |
| outline(mm) | 164.9 × 100 × 6 (H×V×D) |
| bezel area(mm) | 157.08 × 89.39 (H×V) |
| treatment | Antiglare |
| luminance | 1000 cd/m² (Typ.) |
| contrast ratio | 800 : 1 (Typ.) (TM) |
| viewing angle | 70/70/60/70 (Typ.)(CR≥10) |
| response | 25 (Typ.)(Tr+Td) ms |
| good view at | 6 o'clock |
| work mode | TN, Normally White, Transmissive |
| color depth | 16.7M 50% NTSC |
| backlight | 3S8P WLED , 50K hours , No Driver |
| mass | TBD |
| used for | Industrial Outdoor High Brightness Automotive Display |
| refresh rate | 60Hz |
| touchscreen | Without |
| Storage Temp.: -40 ~ 90 °C Operating Temp.: -30 ~ 85 °C ; Vibration Level: 6.8G (66.64 m/s²) |
