| Nama Wahi | TM070RDHG25 |
| Waitohu | TIANMA |
| Rahi | 7.0 |
| Taupānga | Industrial |
| Whakatau | 800×480 |
| Te tito | a-Si TFT-LCD , LCM |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 262K |
| Whakamuri | 3S8P |
| Atanga | |
| panel brand | TIANMA |
| panel size | 7.0" |
| resolution | 800(RGB)×480, WVGA, 134PPI |
| display area | 154.08(W)×85.92(H) mm |
| outline size | 164.9(W)×100(H) ×8.1(D) mm |
| brightness | 450 cd/m² (Typ.) |
| viewing angle | 80/80/60/80 (Typ.)(CR≥10) |
| best view on | 6 o'clock |
| display colors | 262K 50% NTSC |
| frequency | 60Hz |
| weight | TBD |
| panel model | TM070RDHG25 |
| panel type | a-Si TFT-LCD , LCM |
| pixel format | RGB Vertical Stripe |
| bezel opening | 157.08(W)×89.39(H) mm |
| surface | Antiglare |
| contrast ratio | 1000:1 (Typ.) (TM) |
| display mode | TN, Normally White, Transmissive |
| response time | 15 (Typ.)(Tr+Td) |
| lamp type | 3S8P WLED , 20K hours , Without Driver |
| touch screen | Without |
| application | Industrial |
| TM070DDH01 | Tianma | 7.0 | 1024×600 |
| TM070DDH02 | Tianma | 7.0 | 1024×600 |
| TM070DDH03 | Tianma | 7.0 | 1024×600 |
| TM070JDHP01-00 | Tianma | 7.0 | 1280×800 |
| TM070RBH10 | Tianma | 7.0 | 800×480 |
| TM070RDH01 | Tianma | 7.0 | 800×480 |
| TM070RDH10 | Tianma | 7.0 | 800×480 |
| TM070RDH11 | Tianma | 7.0 | 800×480 |
| TM070RDH13 | Tianma | 7.0 | 800×480 |
| TM070WA-22L06 | SANYO | 7.0 | 480×234 |
