| Nama Wahi | TM070RDHG12 |
| Waitohu | TIANMA |
| Rahi | 7.0 |
| Taupānga | Portable DVD Player |
| Whakatau | 800×480 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 500:1 |
| Nga Tae | 262K/16.7M |
| Whakamuri | WLED |
| Atanga | Parallel |
| brand | TIANMA |
| model | TM070RDHG12 |
| diagonal size | 7.0 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 800(RGB)×480 [WVGA] 134PPI |
| configuration | RGB Vertical Stripe |
| active area | 154.08(H)×85.92(V) mm |
| outline dim. | 164.9(H)×100(V) ×6(D) mm |
| bezel area | 157.08(H)×89.39(V) mm |
| treatment | Antiglare |
| luminance | 350 cd/m² (Typ.) |
| contrast ratio | 500:1 (Typ.) (TM) |
| view direction | 12 o'clock |
| response time | 20 (Typ.)(Tr+Td) |
| viewing angle | 70/70/60/70 (Typ.)(CR≥10) |
| operating mode | TN, Normally White, Transmissive |
| support color | 262K/16.7M 50% NTSC |
| light source | WLED [3S7P] , 20K hours , W/O Driver |
| weight | 165g (Typ.) |
| designed for | Portable DVD Player Digital Photo Frame |
| frame rate | 60Hz |
| touch panel | Without |
| interface type | Parallel RGB (1 ch, 6/8-bit) , 60 pins FPC |
| power supply | 3.3/10.6/10.6/-7V (Typ.)(VCC/AVDD/VGH/VGL) |
| environment | Operating Temperature: -20 ~ 70 °C ; Storage Temperature: -30 ~ 80 °C |
| TM070DDH02 | Tianma | 7.0 | 1024×600 |
| TM070DDH03 | Tianma | 7.0 | 1024×600 |
| TM070DDH07 | Tianma | 7.0 | 1024×600 |
| TM070DDH09 | Tianma | 7.0 | 1024×600 |
| TM070RBH10 | Tianma | 7.0 | 800×480 |
| TM070RDH01 | Tianma | 7.0 | 800×480 |
| TM070RDH10 | Tianma | 7.0 | 800×480 |
| TM070RDH11 | Tianma | 7.0 | 800×480 |
| TM070SDH03 | Tianma | 7.0 | 800×600 |
| TM070WA-22L06 | SANYO | 7.0 | 480×234 |
