| Nama Wahi | TM070RDH10-11 |
| Waitohu | TIANMA |
| Rahi | 7.0 |
| Taupānga | Industrial Digital P |
| Whakatau | 800×480 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 500:1 |
| Nga Tae | 262K/16.7M |
| Whakamuri | 3S8P |
| Atanga | Parallel |
| panel brand | TIANMA |
| panel model | TM070RDH10-11 |
| panel size | 7.0" |
| panel type | a-Si TFT-LCD, LCM |
| resolution | 800(RGB)×480, WVGA, 134PPI |
| pixel format | RGB Vertical Stripe |
| display area | 154.08(W)×85.92(H) mm |
| bezel opening | 157.08(W)×89.39(H) mm |
| outline size | 164.9(W)×100(H) ×6(D) mm |
| surface | Antiglare |
| brightness | 350 cd/m² (Typ.) |
| contrast ratio | 500:1 (Typ.) (TM) |
| viewing angle | 70/70/50/70 (Typ.)(CR≥10) |
| display mode | TN, Normally White, Transmissive |
| best view on | 12 o'clock |
| response time | 25 (Typ.)(Tr+Td) |
| display colors | 262K/16.7M 50% NTSC |
| lamp type | 3S8P WLED , 20K hours , Without Driver |
| frequency | 60Hz |
| touch screen | Without |
| panel weight | 160g (Typ.) |
| application | Industrial Digital Photo Frame Portable DVD Player |
| signal interface | Parallel RGB (1 ch, 6/8-bit) , 50 pins FPC |
| input voltage | 3.3/12.5/22.0/-7.0V (Typ.)(VCC/AVDD/VGH/VGL) |
| environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
| 70WVW3A | SII | 7.0 | 800×480 |
| BA070WS1-300 | BOE | 7.0 | 1024×600 |
| C070VVN03.3 | AUO | 7.0 | 800×480 |
| CLAA070LC0FCT | CPT | 7.0 | 800×480 |
| TM070RBH10 | Tianma | 7.0 | 800×480 |
| TM070RDH01 | Tianma | 7.0 | 800×480 |
| TM070RDH10 | Tianma | 7.0 | 800×480 |
| TM070RDH11 | Tianma | 7.0 | 800×480 |
| TM070RDH13 | Tianma | 7.0 | 800×480 |
| TX18D40VM1CAA | KOE | 7.0 | 800×480 |
