| Nama Wahi | TM070RBH10-00 |
| Waitohu | TIANMA |
| Rahi | 7.0 |
| Taupānga | Industrial Digital P |
| Whakatau | 800×480 |
| Te tito | LCM , a-Si TFT-LCD |
| Tirohanga | |
| CR | 500:1 |
| Nga Tae | 262K/16.2M |
| Whakamuri | 3S8P |
| Atanga | Parallel |
| manufacturer | TIANMA |
| model name | TM070RBH10-00 0 Compatible |
| screen size | 7.0 inch |
| screen type | LCM , a-Si TFT-LCD |
| pixel number | 800(RGB)×480 (WVGA) 134PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 154.08 × 85.92 (H×V) |
| outline(mm) | 164.9 × 100 × 7.1 (H×V×D) |
| bezel area(mm) | - |
| treatment | Antiglare |
| luminance | 280 cd/m² (Typ.) |
| contrast ratio | 500 : 1 (Typ.) (TM) |
| viewing angle | 70/70/50/70 (Typ.)(CR≥10) |
| response | 25 (Typ.)(Tr+Td) ms |
| good view at | 12 o'clock |
| work mode | TN, Normally White, Transmissive |
| color depth | 262K/16.2M 49% NTSC |
| backlight | 3S8P WLED , 20K hours , No Driver |
| mass | TBD |
| used for | Industrial Digital Photo Frame Portable DVD Player MP3 PMP |
| refresh rate | 60Hz |
| touchscreen | 4-wire Resistive Touch |
| signal type | Parallel RGB (1 ch, 6/8-bit) , 50 pins FPC |
| voltage supply | 3.3/10.4/16/-7.0V (Typ.)(VCC/AVDD/VGH/VGL) |
| max. ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
| AT070TN83 TP | Innolux | 7.0 | 800×480 |
| CLAA070NP01 | CPT | 7.0 | 1024×600 |
| LQ070T5DR01 | SHARP | 7.0 | 480×240 |
| LQ070Y5DG36 | SHARP | 7.0 | 800×480 |
| PM070WL4 | E Ink | 7.0 | 800×480 |
| TM070RBH10 | Tianma | 7.0 | 800×480 |
| TM070RDH01 | Tianma | 7.0 | 800×480 |
| TM070RDH10 | Tianma | 7.0 | 800×480 |
| TM070RDH11 | Tianma | 7.0 | 800×480 |
| TM070RDH13 | Tianma | 7.0 | 800×480 |
