| Nama Wahi | TM045YDH27 |
| Waitohu | Tianma |
| Rahi | 4.5 |
| Taupānga | MPH |
| Whakatau | 480×854 |
| Te tito | LCM |
| Tirohanga | 280 |
| CR | 500:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | MIPI |
| panel brand | TIANMA |
| panel model | TM045YDH27 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 4.5 inch |
| resolution | 480(RGB)×854 , FWVGA |
| display mode | TN, Normally White, Transmissive |
| active area | 55.44×98.637 mm |
| outline | 60.04×109.1×2.6 mm |
| surface | |
| brightness | 280 cd/m² (Typ.) |
| contrast ratio | 500:1 (Typ.) |
| display colors | 16.7M (8-bit), CIE193164% |
| response time | 25 (Typ.)(Tr+Td) |
| viewing angle | 70/70/70/60 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 8S1PWLEDWithout Driver |
| signal interface | MIPI (2 data lanes), 25 pins |
| input voltage | (1.8/2.8)/2.8V (Typ.)(IOVCC/VCC) |
| application | MPH |
