| Nama Wahi | TCG085WVLCF-G00 |
| Waitohu | Kyocera |
| Rahi | 8.5 |
| Taupānga | Industrial |
| Whakatau | 800×480 |
| Te tito | LCM , a-Si TFT-LCD |
| Tirohanga | |
| CR | 500:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | Parallel |
| manufacturer | Kyocera |
| model name | TCG085WVLCF-G00 |
| screen size | 8.5 inch |
| screen type | LCM , a-Si TFT-LCD |
| pixel number | 800(RGB)×480 (WVGA) 109PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 184.8 × 110.88 (H×V) |
| outline(mm) | 210 × 134 × 11.1 (H×V×D) |
| bezel area(mm) | - |
| treatment | Antiglare |
| luminance | 320 cd/m² (Typ.) |
| contrast ratio | 500 : 1 (Typ.) (TM) |
| viewing angle | 60/60/60/45 (Typ.)(CR≥10) |
| response | 15/35 (Typ.)(Tr/Td) ms |
| good view at | - |
| work mode | TN, Normally White, Transmissive |
| color depth | 262K 49% NTSC |
| backlight | WLED , 50K hours , No Driver |
| mass | TBD |
| used for | Industrial |
| refresh rate | 60Hz |
| touchscreen | 4-wire Resistive Touch, G/G |
| signal type | Parallel RGB (1 ch, 6-bit) , 40 pins Connector |
| voltage supply | 3.3V (Typ.) |
| max. ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
