| Nama Wahi | T420HW02 V0 |
| Waitohu | AUO |
| Rahi | 42 |
| Taupānga | LCTV |
| Whakatau | 1920×1080 |
| Te tito | LCM |
| Tirohanga | 500 |
| CR | 2500:1 |
| Nga Tae | 16.7M |
| Whakamuri | CCFL |
| Atanga | LVDS |
| panel brand | AUO |
| panel model | T420HW02 V0 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 42 inch |
| resolution | 1920(RGB)×1080 , FHD |
| display mode | AMVA, Normally Black, Transmissive |
| active area | 930.24×523.26 mm |
| outline | 983×576 mm |
| surface | Antiglare (Haze 11%), Hard coating (3H) |
| brightness | 500 cd/m² (Typ.) |
| contrast ratio | 2500:1 (Typ.) |
| display colors | 16.7M (8-bit), CIE193172% |
| response time | 15/5 (Typ.)(Tr/Td); 6.5 (Typ.)(G to G) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 18 pcsCCFLEmbedded (Inverter) |
| signal interface | LVDS (2 ch, 8-bit), 51 pins |
| input voltage | 12.0V (Typ.) |
| application | LCTV |
| T420HB01 V1 | AUO | 42 | 1920×1080 |
| T420HVN02.0 | AUO | 42 | 1920×1080 |
| T420HVN02.1 | AUO | 42 | 1920×1080 |
| T420HVN04.0 CELL | AUO | 42 | 1920×1080 |
| T420HVN04.5 CELL | AUO | 42 | 1920×1080 |
| T420HVN08.0 | AUO | 42 | 1920×1080 |
| T420HW06 V5 | AUO | 42 | 1920×1080 |
| T420HW07 V4 | AUO | 42 | 1920×1080 |
| T420HW07 V7 | AUO | 42 | 1920×1080 |
| T420HW08 V0 CELL | AUO | 42 | 1920×1080 |
| LC320DXJ-SFK1 | LG Display | 31.5 | 1366×768 |
| LC320EXE-SDA1 | LG Display | 31.5 | 1366×768 |
| LC320WXN-SAC1 | LG Display | 31.5 | 1366×768 |
| LC420DUH-FGP1 | LG Display | 42 | 1920×1080 |
| LTA320AN12 | Samsung | 31.5 | 1366×768 |
| LTA460HF05 | Samsung | 46 | 1920×1080 |
| LTA520HB03-001 | Samsung | 52 | 1920×1080 |
| LTA550HW04 | Samsung | 55 | 1920×1080 |
| T315XW03 VF | AUO | 31.5 | 1366×768 |
| V420H2-LN1 | Innolux | 42 | 1920×1080 |
