T320XVN02.G CELL

T320XVN02.G CELL
T320XVN02.G CELL thumb
Waitohu
AUO
Rahi
32.0
Taupānga
TV Sets
Whakatau
1366×768
Te tito
CELL ,   a-Si TFT-LC
Tirohanga
CR
3000:1
Nga Tae
16.7M
Whakamuri
No
Atanga
LVDS
In Stock
6498
Whakatakotoranga

Nama Wahi T320XVN02.G CELL
WaitohuAUO
Rahi32.0
TaupāngaTV Sets
Whakatau1366×768
Te titoCELL ,   a-Si TFT-LC
Tirohanga
CR3000:1
Nga Tae16.7M
WhakamuriNo
AtangaLVDS
manufacturerAUO
screen size32.0 inch
pixel number1366×768(RGB)   (WXGA)  49PPI
active area(mm)697.685 × 392.256 (H×V)
bezel area(mm)-
luminance0 cd/m²
viewing angle89/89/89/89 (Typ.)(CR≥10)
good view atSymmetry
glass thickness0.50+0.50 mm
color depth16.7M   70% NTSC
mass880g (Typ.)
refresh rate60Hz
driver ic listBuilt-in COF 1 source chips
signal typeLVDS (1 ch, 8-bit) , 30 pins Connector
voltage supply12.0V (Typ.)
max. ratingsStorage Temp.: -20 ~ 60 °C    Operating Temp.: 0 ~ 50 °C
model nameT320XVN02.G CELL
screen typeCELL ,   a-Si TFT-LCD
arrangementRGB Horizontal Stripe
outline(mm)713.685 × 408.72 × 1.4 (H×V×D)
treatmentAntiglare (Haze 2%), Hard coating (3H)
contrast ratio3000 : 1 (Typ.) (TM)
response8 (Typ.)(G to G) ms
work modeAMVA, Normally Black, Transmissive
transmissivity6.5% (Typ.)(with Polarizer)
backlightNo B/L
used forTV Sets
touchscreenWithout
