T260XW03 V3


Waitohu
AUO
Rahi
26.0
Taupānga
LCTV
Whakatau
1366×768
Te tito
LCM
Tirohanga
500
CR
800:1
Nga Tae
16.7M
Whakamuri
CCFL
Atanga
LVDS
In Stock
2
Whakatakotoranga

Nama Wahi T260XW03 V3
WaitohuAUO
Rahi26.0
TaupāngaLCTV
Whakatau1366×768
Te titoLCM
Tirohanga500
CR800:1
Nga Tae16.7M
WhakamuriCCFL
AtangaLVDS
panel brandAUO
panel modelT260XW03 V3
panel type a-Si TFT-LCD , LCM
panel size26.0 inch
resolution1366(RGB)×768 , WXGA
display modeTN, Normally White, Transmissive
active area575.769×323.712 mm
outline626×373 mm
surfaceAntiglare, Hard coating (3H)
brightness500 cd/m² (Typ.)
contrast ratio800:1 (Typ.)
display colors16.7M (8-bit)
response time6/2 (Typ.)(Tr/Td)
viewing angle80/80/80/80 (Typ.)(CR≥10)(L/R/U/D)
frequency60Hz
lamp typeCCFLEmbedded (Inverter)
signal interfaceLVDS (1 ch, 8-bit), 30 pins
input voltage12.0V (Typ.)
applicationLCTV
Tauira Whanau
T260XVN01.0 AUO 26.0 1366×768
T260XW02 V5 AUO 26.0 1366×768
T260XW02 V9 AUO 26.0 1366×768
T260XW02 VB AUO 26.0 1366×768
T260XW02 VK AUO 26.0 1366×768
T260XW02 VL AUO 26.0 1366×768
T260XW02 VS AUO 26.0 1366×768
T260XW03 V0 AUO 26.0 1366×768
T260XW04 V5 AUO 26.0 1366×768
T260XW06 V4 AUO 26.0 1366×768
