Nama Wahi | T260XVN01.0 |
Waitohu | AUO |
Rahi | 26.0 |
Taupānga | LCTV |
Whakatau | 1366×768 |
Te tito | LCM |
Tirohanga | 300 |
CR | 3000:1 |
Nga Tae | 16.7M |
Whakamuri | WLED |
Atanga | LVDS |
panel brand | AUO |
panel model | T260XVN01.0 |
panel type | a-Si TFT-LCD , LCM |
panel size | 26.0 inch |
resolution | 1366(RGB)×768 , WXGA |
display mode | AMVA3, Normally Black, Transmissive |
active area | 575.769×323.712 mm |
outline | 609.8×357.8 mm |
surface | Antiglare (Haze 2%), Hard coating (3H) |
brightness | 300 cd/m² (Typ.) |
contrast ratio | 3000:1 (Typ.) |
display colors | 16.7M (6-bit + Hi-FRC), CIE193168% |
response time | 6.5 (Typ.)(G to G) |
viewing angle | 89/89/89/89 (Typ.)(CR≥10)(L/R/U/D) |
frequency | 60Hz |
lamp type | WLEDWithout Driver |
signal interface | LVDS (1 ch, 8-bit), 30 pins |
input voltage | 12.0V (Typ.) |
application | LCTV |
