| Nama Wahi | S050WV49 |
| Waitohu | CDTECH |
| Rahi | 5.0 |
| Taupānga | Automotive Display I |
| Whakatau | 800×480 |
| Te tito | LCM, a-Si TFT-LCD |
| Tirohanga | |
| CR | 600:1 |
| Nga Tae | 16.7M |
| Whakamuri | 6S2P |
| Atanga | Parallel |
| manufacturer | CDTECH |
| model name | S050WV49 |
| screen size | 5.0 inch |
| screen type | LCM, a-Si TFT-LCD |
| pixel number | 800(RGB)×480 (WVGA) 188PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 108 × 64.8 (H×V) |
| outline(mm) | 120.7 × 75.8 × 3.2 (H×V×D) |
| bezel area(mm) | 110.6 × 67.6 (H×V) |
| treatment | - |
| luminance | 350 cd/m² (Typ.) |
| contrast ratio | 600 : 1 (Typ.) (TM) |
| viewing angle | 65/65/55/65 (Typ.)(CR≥10) |
| response | 20/20 (Typ.)(Tr/Td) ms |
| good view at | 12 o'clock |
| work mode | TN, Normally White, Transmissive |
| color depth | 16.7M 50% NTSC |
| backlight | 6S2P WLED , 25K hours , No Driver |
| mass | TBD |
| used for | Automotive Display Industrial |
| refresh rate | 60Hz |
| touchscreen | Without |
| signal type | Parallel RGB (1 ch, 8-bit) , FPC 40 pins |
| voltage supply | 3.3/10.4/16.0/-6.0V (Typ.)(DVDD/AVDD/VGH/VGL) |
| max. ratings | Storage Temp.: -30 ~ 80 °C Operating Temp.: -20 ~ 70 °C |
