| Nama Wahi | S035V04-T |
| Waitohu | CDTECH |
| Rahi | 3.5 |
| Taupānga | Industrial Handheld |
| Whakatau | 480×640 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 500:1 |
| Nga Tae | 262K |
| Whakamuri | 8S1P |
| Atanga | Parallel |
| panel brand | CDTECH |
| panel model | S035V04-T |
| panel size | 3.5" |
| panel type | a-Si TFT-LCD, LCM |
| resolution | 480(RGB)×640, VGA, 228PPI |
| pixel format | RGB Vertical Stripe |
| display area | 53.28(W)×71.04(H) mm |
| bezel opening | - |
| outline size | 64(W)×85(H) ×5(D) mm |
| surface | - |
| brightness | 650 cd/m² (Typ.) |
| contrast ratio | 500:1 (Typ.) (TM) |
| viewing angle | 65/65/55/65 (Typ.)(CR≥10) |
| display mode | TN, Normally White, Transmissive |
| best view on | 9 o'clock |
| response time | 30 (Typ.)(Tr+Td) |
| display colors | 262K 50% NTSC |
| lamp type | 8S1P WLED , 25K hours , Without Driver |
| frequency | 60Hz |
| touch screen | 4-wire Resistive Touch |
| panel weight | TBD |
| application | Industrial Handheld & PDA |
| signal interface | Parallel RGB (1 ch, 6-bit) , 39 pins FPC |
| input voltage | 3.3/3.3V (Typ.)(VCC/IOVCC) |
| environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
