| Nama Wahi | S032Q10 |
| Waitohu | CDTECH |
| Rahi | 3.2 |
| Taupānga | Handheld & PDA |
| Whakatau | 240×320 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 350:1 |
| Nga Tae | 262K |
| Whakamuri | 1S5P |
| Atanga | CPU |
| panel brand | CDTECH |
| panel model | S032Q10 |
| panel size | 3.2" |
| panel type | a-Si TFT-LCD, LCM |
| resolution | 240(RGB)×320, QVGA, 127PPI |
| pixel format | RGB Vertical Stripe |
| display area | 47.88(W)×63.84(H) mm |
| bezel opening | - |
| outline size | 55.04(W)×77.7(H) ×2.5(D) mm |
| surface | - |
| brightness | 270 cd/m² (Typ.) |
| contrast ratio | 350:1 (Typ.) (TM) |
| viewing angle | 55/65/65/65 (Typ.)(CR≥10) |
| display mode | TN, Normally White, Transmissive |
| best view on | 9 o'clock |
| response time | 20 (Typ.)(Tr+Td) |
| display colors | 262K |
| lamp type | 1S5P WLED , 25K hours , Without Driver |
| frequency | - |
| touch screen | Without |
| panel weight | TBD |
| application | Handheld & PDA |
| signal interface | CPU , 37 pins FPC |
| input voltage | 3.3/3.3V (Max.)(VCC/IOVCC) |
| environment | Operating Temp.: -20 ~ 70 °C ; Storage Temp.: -30 ~ 80 °C |
