RGC13128096FH004


Waitohu
RiTdisplay
Rahi
1.3
Taupānga
Handheld & PDA
Whakatau
128×96
Te tito
PM-OLED, OLED
Tirohanga
CR
2000:1
Nga Tae
65K/262K
Whakamuri
self
Atanga
8-bit
In Stock
19553
Whakatakotoranga

Nama Wahi RGC13128096FH004
WaitohuRiTdisplay
Rahi1.3
TaupāngaHandheld & PDA
Whakatau128×96
Te titoPM-OLED, OLED
Tirohanga
CR2000:1
Nga Tae65K/262K
Whakamuriself
Atanga8-bit
brandRiTdisplay
modelRGC13128096FH004
diagonal size1.3 inch
typePM-OLED, OLED
pixel format128(RGB)×96  123PPI
configurationRGB Vertical Stripe
active area26.279(H)×19.708(V) mm
outline dim.33(H)×25.8(V) ×1.31(D) mm
bezel area28.3(H)×21.7(V) mm
treatmentAntiglare
luminance90 cd/m² (Typ.)
contrast ratio2000:1 (Min.) (TM)
view directionSymmetry
response time0.01 (Typ.)
viewing angle80/80/80/80 (Min.)
operating mode-
support color65K/262K   66% NTSC
light sourceself , 11K hours
weight2.30±0.23g
designed forHandheld & PDA
frame rate105Hz
touch panelWithout
d-ic detailCOF Built-in SSD1351UR1
interface type8-bit 6800/8080 parallel , 30 pins FPC
power supply15/2.8/1.8V (Typ.)(VCC/VCI/VDDIO)
environmentOperating Temperature: -40 ~ 70 °C ; Storage Temperature: -40 ~ 85 °C
