| Nama Wahi | PT236AT01-1 |
| Waitohu | HKC |
| Rahi | 23.6 |
| Taupānga | TV Sets |
| Whakatau | 1366×768 |
| Te tito | CELL , a-Si TFT-LC |
| Tirohanga | |
| CR | 3000:1 |
| Nga Tae | 16.7M |
| Whakamuri | No |
| Atanga | |
| manufacturer | HKC |
| screen size | 23.6 inch |
| pixel number | 1366(RGB)×768 (WXGA) 66PPI |
| active area(mm) | 521.471 × 293.184 (H×V) |
| bezel area(mm) | - |
| luminance | 0 (cd/m²) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| good view at | Symmetry |
| glass thickness | 0.50+0.50 mm |
| color depth | 16.7M 68% NTSC |
| mass | 500g (Typ.) |
| refresh rate | 60Hz |
| model name | PT236AT01-1 |
| screen type | CELL , a-Si TFT-LCD |
| arrangement | RGB Vertical Stripe |
| outline(mm) | 535.471 × 306.404 × 1.37 (H×V×D) |
| treatment | Antiglare (Haze 3%), Hard coating (3H) |
| contrast ratio | 3000 : 1 (Typ.) (TM) |
| work mode | FSA, Normally Black, Transmissive |
| response | 9.5 (Typ.)(G to G) ms |
| transmissivity | 6.0% (Typ.)(with Polarizer) |
| backlight | No B/L |
| used for | TV Sets |
| touchscreen | Without |
