| Nama Wahi | PD050OX1 |
| Waitohu | E Ink |
| Rahi | 5.0 |
| Taupānga | IA |
| Whakatau | 480×480 |
| Te tito | LCM |
| Tirohanga | 450 |
| CR | 400:1 |
| Nga Tae | 262K |
| Whakamuri | CCFL |
| Atanga | TTL |
| panel brand | PVI |
| panel model | PD050OX1 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 5.0 inch |
| resolution | 480(RGB)×480 |
| display mode | TN, Normally White, Transmissive |
| active area | 90×90 mm |
| outline | 115.5×110×7.5 mm |
| surface | Antiglare |
| brightness | 450 cd/m² (Typ.) |
| contrast ratio | 400:1 (Typ.) |
| display colors | 262K (6-bit) |
| response time | 15/25 (Typ.)(Tr/Td) |
| viewing angle | 60/60/40/50 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 1 pcsCCFLWithout Driver |
| signal interface | TTL (1 ch, 6-bit), 60 pins |
| input voltage | 3.3/3.3/9.7/19.0V (Typ.)(VCC/VDD1/VDD2/VGG/VEE) |
| application | IA |
