| Nama Wahi | P101DCZ-3Z0 |
| Waitohu | Innolux |
| Rahi | 10.1 |
| Taupānga | Pad & Tablet |
| Whakatau | 800×1280 |
| Te tito | CELL , a-Si TFT-LC |
| Tirohanga | |
| CR | 800:1 |
| Nga Tae | 16.7M |
| Whakamuri | No |
| Atanga | MIPI |
| manufacturer | Innolux |
| screen size | 10.1 inch |
| pixel number | 800(RGB)×1280 (WXGA) 150PPI |
| active area(mm) | 135.36 × 216.576 (H×V) |
| bezel area(mm) | - |
| luminance | 0 cd/m² |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10) |
| good view at | Symmetry |
| glass thickness | - |
| color depth | 16.7M 59% NTSC |
| mass | - |
| refresh rate | 60Hz |
| signal type | MIPI (4 data lanes) , 40 pins Connector |
| voltage supply | 3.3/5.8/-5.8V (Typ.)(VDDIN/AVDD/AVEE) |
| max. ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
| model name | P101DCZ-3Z0 |
| screen type | CELL , a-Si TFT-LCD |
| arrangement | RGB Vertical Stripe |
| outline(mm) | - |
| treatment | Clear, Hard coating (3H) |
| contrast ratio | 800 : 1 (Typ.) (TM) |
| response | 25 (Typ.)(Tr+Td) ms |
| work mode | AAS, Normally Black, Transmissive |
| transmissivity | 4.73% (Typ.)(with Polarizer) |
| backlight | No B/L |
| used for | Pad & Tablet |
| touchscreen | Without |
