Nama Wahi | OEL1M6013-W-E |
Waitohu | TRULY |
Rahi | 1.3 |
Taupānga | Wearable Instruments |
Whakatau | 128×96 |
Te tito | PM-OLED , OLED |
Tirohanga | |
CR | 5000:1 |
Nga Tae | Grayscale |
Whakamuri | self |
Atanga | 4-wire |
brand | TRULY |
diagonal size | 1.3 inch |
pixel format | 128×96 121PPI |
active area | 26.86(H)×20.14(V) mm |
bezel area | 28.86(H)×22.14(V) mm |
luminance | 70 cd/m² (Typ.) |
view direction | Symmetry |
viewing angle | 80/80/80/80 |
support color | Grayscale |
weight | - |
frame rate | 105Hz |
d-ic detail | COG Built-in SSD1327ZB |
interface type | 4-wire SPI , 16 pins FPC |
power supply | 3.0/15.0V (Typ.)(VCI/VCC) |
environment | Operating Temperature: -40 ~ 70 °C ; Storage Temperature: -40 ~ 80 °C |
model | OEL1M6013-W-E |
type | PM-OLED , OLED |
configuration | Rectangle |
outline dim. | 32.6(H)×28.3(V) mm |
treatment | - |
contrast ratio | 5000:1 (Min.) (TM) |
response time | 0.02/0.02 (Typ.)(Tr/Td) |
operating mode | - |
light source | self , 30K hours |
designed for | Wearable Instruments & Meters |
touch panel | Without |
