Nama Wahi | MXS4169 |
Waitohu | Soar |
Rahi | 1.1 |
Taupānga | Wearable |
Whakatau | 96×96 |
Te tito | PM-OLED , OLED |
Tirohanga | |
CR | - |
Nga Tae | Mono(White) |
Whakamuri | self |
Atanga | 8-bit |
brand | Soar |
diagonal size | 1.1 inch |
pixel format | 96×96 121PPI |
active area | 20.13(H)×20.13(V) mm |
luminance | 140 cd/m² (Typ.) |
view direction | - |
viewing angle | - |
support color | Mono(White) |
weight | 2.6g (Typ.) |
frame rate | - |
interface type | 8-bit parallel , 24 pins FPC |
model | MXS4169 |
type | PM-OLED , OLED |
configuration | Rectangle |
outline dim. | 27(H)×30.1(V) mm |
contrast ratio | - |
response time | - |
operating mode | - |
light source | self , 43K hours |
designed for | Wearable |
touch panel | Without |
