M270HW01 V1

M270HW01 V1
M270HW01 V1
M270HW01 V1 thumb M270HW01 V1 thumb
Waitohu
AUO
Rahi
27.0
Taupānga
DMPC
Whakatau
1920×1080
Te tito
LCM
Tirohanga
400
CR
1000:1
Nga Tae
16.7M
Whakamuri
CCFL
Atanga
LVDS
In Stock
7207
Whakatakotoranga

Nama Wahi M270HW01 V1
WaitohuAUO
Rahi27.0
TaupāngaDMPC
Whakatau1920×1080
Te titoLCM
Tirohanga400
CR1000:1
Nga Tae16.7M
WhakamuriCCFL
AtangaLVDS
panel brandAUO
panel modelM270HW01 V1
panel type a-Si TFT-LCD , LCM
panel size27.0 inch
resolution1920(RGB)×1080 , FHD
display modeTN, Normally White, Transmissive
active area597.6×336.15 mm
outline630×368.2 mm
surfaceAntiglare, Hard coating (3H)
brightness400 cd/m² (Typ.)
contrast ratio1000:1 (Typ.)
display colors16.7M (8-bit)
response time3.8/1.2 (Typ.)(Tr/Td)
viewing angle85/85/80/80 (Typ.)(CR≥10)(L/R/U/D)
frequency60Hz
lamp type4 pcsCCFLWithout Driver
signal interfaceLVDS (2 ch, 8-bit), 30 pins
input voltage5.0V (Typ.)
applicationDMPC
