Innolux M270HHF-L10 Raraunga Raarangi, Whakatakotoranga, rakau, tono www.looklcd-no.com
LookLCD LookLCD


M270HHF-L10

M270HHF-L10
M270HHF-L10
M270HHF-L10
M270HHF-L10 thumb M270HHF-L10 thumb M270HHF-L10 thumb
Waitohu
Innolux
Rahi
27.0
Taupānga
DMPC
Whakatau
1920×1080
Te tito
LCM
Tirohanga
300
CR
1000:1
Nga Tae
16.7M
Whakamuri
WLED
Atanga
LVDS
In Stock
12067
Whakatakotoranga

Nama Wahi M270HHF-L10
WaitohuInnolux
Rahi27.0
TaupāngaDMPC
Whakatau1920×1080
Te titoLCM
Tirohanga300
CR1000:1
Nga Tae16.7M
WhakamuriWLED
AtangaLVDS
panel brandCHIMEI INNOLUX
panel modelM270HHF-L10
panel type a-Si TFT-LCD , LCM
panel size27.0 inch
resolution1920(RGB)×1080 , FHD
display modeTN, Normally White, Transmissive
active area597.888×336.312 mm
outline630×368.2×16.4 mm
surfaceAntiglare (Haze 25%), Hard coating (3H)
brightness300 cd/m² (Typ.)
contrast ratio1000:1 (Typ.)
display colors16.7M (8-bit), CIE193172%
response time0.8/2.6 (Typ.)(Tr/Td)
viewing angle85/85/80/80 (Typ.)(CR≥10)(L/R/U/D)
frequency120Hz
lamp type4 stringsWLEDWithout Driver
signal interfaceLVDS (4 ch, 8-bit), 92 pins
input voltage12.0V (Typ.)
applicationDMPC
