| Nama Wahi | M270HTN02.2 CELL |
| Waitohu | AUO |
| Rahi | 27.0 |
| Taupānga | Desktop Monitor Gami |
| Whakatau | 1920×1080 |
| Te tito | a-Si TFT-LCD , CELL |
| Tirohanga | |
| CR | 1000:1 |
| Nga Tae | 16.7M |
| Whakamuri | No |
| Atanga | V-by-One |
| panel brand | AUO |
| panel size | 27.0" |
| resolution | 1920(RGB)×1080, FHD, 81PPI |
| display area | 597.6(W)×336.15(H) mm |
| outline size | 608.3(W)×349.3(H) ×1.5(D) mm |
| brightness | 0 cd/m² |
| viewing angle | 85/85/80/80 (Typ.)(CR≥10) |
| best view on | 6 o'clock |
| glass depth | 0.50+0.50 mm |
| display colors | 16.7M 71% NTSC |
| frequency | 144Hz |
| driver ic | COF Built-in 6 source chips |
| panel weight | 665g (Typ.) |
| signal interface | V-by-One 8 lane , 40 pins Connector |
| input voltage | 12.0V (Typ.) |
| environment | Operating Temp.: 0 ~ 50 °C ; Storage Temp.: -20 ~ 60 °C |
| panel model | M270HTN02.2 CELL |
| panel type | a-Si TFT-LCD , CELL |
| pixel format | RGB Vertical Stripe |
| bezel opening | - |
| surface | Antiglare, Hard coating (3H) |
| contrast ratio | 1000:1 (Typ.) (TM) |
| display mode | TN, Normally White, Transmissive |
| response time | 3.8/1.2 (Typ.)(Tr/Td) |
| transmissivity | 5.3% (Typ.)(with Polarizer) |
| lamp type | No B/L |
| touch screen | Without |
| application | Desktop Monitor Gaming |
