| Nama Wahi | M080AWP9 R0 |
| Waitohu | IVO |
| Rahi | 8.0 |
| Taupānga | Automotive Display |
| Whakatau | 800×480 |
| Te tito | a-Si TFT-LCD, LCM |
| Tirohanga | |
| CR | 700:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | Parallel |
| brand | IVO |
| model | M080AWP9 R0 |
| diagonal size | 8.0 inch |
| type | a-Si TFT-LCD, LCM |
| pixel format | 800(RGB)×480 [WVGA] 115PPI |
| configuration | RGB Vertical Stripe |
| active area | 175.2(H)×105.12(V) mm |
| outline dim. | 186.5(H)×117.22(V) ×6.65(D) mm |
| bezel area | 177.4(H)×107.32(V) mm |
| treatment | Antiglare |
| luminance | 750 cd/m² (Typ.) |
| contrast ratio | 700:1 (Typ.) (TM) |
| view direction | - |
| response time | 13 (Typ.)(Tr+Td) |
| viewing angle | 70/70/50/70 (Typ.)(CR≥10) |
| operating mode | TN, Normally White, Transmissive |
| support color | 262K 70% NTSC |
| light source | WLED [7S3P] , 30K hours , W/O Driver |
| weight | 195/215g (Typ./Max.) |
| designed for | Automotive Display |
| frame rate | 60Hz |
| touch panel | Without |
| interface type | Parallel RGB (1 ch, 6-bit) , 60 pins FPC |
| power supply | 3.3/10.6/22/-7.0V (Typ.)(VCC/VDDA/VGH/VGL) |
| environment | Operating Temperature: -30 ~ 85 °C ; Storage Temperature: -40 ~ 95 °C |
