| Nama Wahi | LTV250QV-F03 |
| Waitohu | Samsung |
| Rahi | 2.5 |
| Taupānga | DSC |
| Whakatau | 320×240 |
| Te tito | LCM |
| Tirohanga | 220 |
| CR | 300:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | TTL |
| panel brand | SAMSUNG |
| panel model | LTV250QV-F03 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 2.5 inch |
| resolution | 320(RGB)×240 , QVGA |
| display mode | TN, TMR |
| active area | 50.88×38.04 mm |
| outline | 56.98×47.94 mm |
| surface | |
| brightness | 220 cd/m² (Typ.) |
| contrast ratio | 300 : 1 (Typ.) |
| display colors | 16.7M (8-bit) |
| response time | 25 (Typ.)(Tr+Td) |
| viewing angle | 80/80/80/65 (Typ.)(CR≥10)(L/R/U/D) |
| lamp type | 4S1PWLEDWithout Driver |
| signal interface | Parallel RGB (1 ch, 8-bit) + SPI, 51 pins |
| input voltage | 3.3/5.0V (Typ.)(DVDD/AVDD) |
| application | DSC |
