| Nama Wahi | LTM238HP01 |
| Waitohu | SAMSUNG |
| Rahi | 23.8 |
| Taupānga | Desktop Monitor |
| Whakatau | 1920×1080 |
| Te tito | LCM , a-Si TFT-LCD |
| Tirohanga | |
| CR | 3000:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| manufacturer | SAMSUNG |
| model name | LTM238HP01 |
| screen size | 23.8 inch |
| screen type | LCM , a-Si TFT-LCD |
| pixel number | 1920(RGB)×1080 (FHD) 92PPI |
| arrangement | RGB Vertical Stripe |
| active area(mm) | 527.04 × 296.46 (H×V) |
| outline(mm) | - |
| luminance | - |
| contrast ratio | 3000 : 1 (Typ.) (TM) |
| viewing angle | 89/89/89/89 (Typ.)(CR≥10) |
| response | 14 (Typ.)(G to G) ms |
| good view at | Symmetry |
| work mode | PVA, Normally Black, Transmissive |
| color depth | 16.7M 72% NTSC |
| backlight | WLED |
| mass | - |
| used for | Desktop Monitor |
| refresh rate | 60Hz |
| touchscreen | Without |
| signal type | LVDS (2 ch, 8-bit) , 30 pins Connector |
| voltage supply | 5.0V (Typ.) |
| max. ratings | Storage Temp.: -20 ~ 60 °C Operating Temp.: 0 ~ 50 °C |
