| Nama Wahi | LTM170W1-L01 |
| Waitohu | Samsung |
| Rahi | 17.0 |
| Taupānga | DMPC |
| Whakatau | 1280×768 |
| Te tito | LCM |
| Tirohanga | 450 |
| CR | 400:1 |
| Nga Tae | 16.2M |
| Whakamuri | CCFL |
| Atanga | LVDS |
| panel brand | SAMSUNG |
| panel model | LTM170W1-L01 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 17.0 inch |
| resolution | 1280(RGB)×768 , WXGA |
| display mode | TN, Normally White, Transmissive |
| active area | 370.56×222.336 mm |
| outline | 404×258×16.7 mm |
| surface | Antiglare (Haze 25%), Hard coating (3H) |
| brightness | 450 cd/m² (Typ.) |
| contrast ratio | 400:1 (Typ.) |
| display colors | 16.2M (6-bit + FRC) |
| response time | 5/20 (Typ.)(Tr/Td) |
| viewing angle | 70/70/50/60 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 4 pcsCCFLWithout Driver |
| signal interface | LVDS (1 ch, 8-bit), 20 pins |
| input voltage | 3.3V (Typ.) |
| application | DMPC |
