Waitohu
Samsung
Rahi
17.0
Taupānga
DMPC
Whakatau
1280×1024
Te tito
LCM
Tirohanga
300
CR
700:1
Nga Tae
16.2M
Whakamuri
CCFL
Atanga
LVDS
In Stock
21
Whakatakotoranga

Nama Wahi LTM170EU-L11
WaitohuSamsung
Rahi17.0
TaupāngaDMPC
Whakatau1280×1024
Te titoLCM
Tirohanga300
CR700:1
Nga Tae16.2M
WhakamuriCCFL
AtangaLVDS
panel brandSAMSUNG
panel modelLTM170EU-L11 1 Compatible model
panel type a-Si TFT-LCD , LCM
panel size17.0 inch
resolution1280(RGB)×1024 , SXGA
display modeTN, Normally White, Transmissive
active area337.92×270.336 mm
outline358.5×296.5×17.5 mm
surfaceAntiglare (Haze 25%), Hard coating (3H)
brightness300 cd/m² (Typ.)
contrast ratio700:1 (Typ.)
display colors16.2M (6-bit + FRC), CIE193172%
response time2/6 (Typ.)(Tr/Td)
viewing angle75/75/75/60 (Typ.)(CR≥10)(L/R/U/D)
frequency60Hz
lamp type4 pcsCCFLWithout Driver
signal interfaceLVDS (2 ch, 8-bit), 30 pins
input voltage5.0V (Typ.)
applicationDMPC
