| Nama Wahi | LTM12C505D |
| Waitohu | TOSHIBA |
| Rahi | 12.1 |
| Taupānga | NBPC |
| Whakatau | 1024×768 |
| Te tito | LCM |
| Tirohanga | 165 |
| CR | 350:1 |
| Nga Tae | 262K |
| Whakamuri | CCFL |
| Atanga | LVDS |
| panel brand | Toshiba Matsushita |
| panel model | LTM12C505D |
| panel type | LTPS TFT-LCD , LCM |
| panel size | 12.1 inch |
| resolution | 1024(RGB)×768 , XGA |
| display mode | TN, Normally White, Transmissive |
| active area | 245.76×184.32 mm |
| outline | 261×199×5.3 mm |
| surface | |
| brightness | 165 cd/m² (Typ.) |
| contrast ratio | 350:1 (Typ.) |
| display colors | 262K (6-bit) |
| response time | 50/50 (Max.)(Tr/Td) |
| viewing angle | |
| frequency | 60Hz |
| lamp type | 1 pcsCCFLEmbedded (Inverter) |
| signal interface | LVDS (1 ch, 6-bit), 20 pins |
| input voltage | 3.3V (Typ.) |
| application | NBPC |
