| Nama Wahi | LTL106AL01-002 |
| Waitohu | Samsung |
| Rahi | 10.6 |
| Taupānga | PAD |
| Whakatau | 1366×768 |
| Te tito | LCM |
| Tirohanga | 400 |
| CR | 800:1 |
| Nga Tae | 16.7M |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | SAMSUNG |
| panel model | LTL106AL01-002 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 10.6 inch |
| resolution | 1366(RGB)×768 , WXGA |
| display mode | PLS, Normally Black, Transmissive |
| active area | 234.72×132.03 mm |
| outline | 246.52×149.02×5.2 mm |
| surface | Glare (Haze 0%), Hard coating (2H) |
| brightness | 400 cd/m² (Typ.) |
| contrast ratio | 800:1 (Typ.) |
| display colors | 16.7M (8-bit), CIE193150% |
| response time | 16 (Typ.)(Tr+Td) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 8-bit), 30 pins |
| input voltage | 3.3V (Typ.) |
| application | PAD |
