| Nama Wahi | LTL089CL02-W02 |
| Waitohu | Samsung |
| Rahi | 8.9 |
| Taupānga | PAD |
| Whakatau | 1920×1200 |
| Te tito | LCM |
| Tirohanga | 450 |
| CR | 900:1 |
| Nga Tae | 262K |
| Whakamuri | WLED |
| Atanga | MIPI |
| panel brand | SAMSUNG |
| panel model | LTL089CL02-W02 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 8.9 inch |
| resolution | 1920(RGB)×1200 , WUXGA |
| display mode | PLS, Normally Black, Transmissive |
| active area | 191.52×119.7 mm |
| outline | 203.5×135.9×5.2 mm |
| surface | Glare (Haze 0%), Hard coating (2H) |
| brightness | 450 cd/m² (Typ.) |
| contrast ratio | 900:1 (Typ.) |
| display colors | 262K (6-bit) |
| response time | 16 (Typ.)(Tr+Td) |
| viewing angle | 85/85/85/85 (Typ.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | 7S5PWLEDWithout Driver |
| signal interface | MIPI (4 data lanes), 45 pins |
| input voltage | 3.3V (Typ.) |
| application | PAD |
