| Nama Wahi | LTL070NL02-W02 |
| Waitohu | Samsung |
| Rahi | 7.0 |
| Taupānga | PAD |
| Whakatau | 1024×600 |
| Te tito | LCM |
| Tirohanga | |
| CR | 800:1 |
| Nga Tae | 16.2M |
| Whakamuri | WLED |
| Atanga | LVDS |
| panel brand | SAMSUNG |
| panel model | LTL070NL02-W02 |
| panel type | a-Si TFT-LCD , LCM |
| panel size | 7.0 inch |
| resolution | 1024(RGB)×600 , WSVGA |
| display mode | PLS, Normally Black, Transmissive |
| active area | 153.6×90 mm |
| surface | |
| brightness | |
| contrast ratio | 800:1 (Typ.) |
| display colors | 16.2M (6-bit + FRC), CIE193150% |
| response time | 30 (Typ.)(Tr+Td) |
| viewing angle | 80/80/80/80 (Min.)(CR≥10)(L/R/U/D) |
| frequency | 60Hz |
| lamp type | WLEDEmbedded (LED Driver) |
| signal interface | LVDS (1 ch, 8-bit) |
| application | PAD |
